Physics Exam Past Questions and Answers | JAMB, WAEC and NECO

Physics is the science that studies the nature and properties of matter and energy. It covers topics like motion, heat, light, sound, electricity, magnetism, and the structure of atoms.

• Question 821: If a current of 2.5A flows through an electrolyte for 3 hours and 1.8g of a substance is deposited, what is the mass of the substance that will be deposited if a current of 4A flows through it for 4.8 hours? Options:
  A) 2.4g
  B) 3.2g
  C) 4.6g
  D) 4.8g
  Show Answer
  The correct answer is C .
• Question 822: A hydraulic press has a large circular piston of radius 0.8m and a circular plunger of radius 0.2m. A force of 500N is exerted by the plunger. Find the force exerted on the piston Options:
  A) 8000N
  B) 4000N
  C) 2000N
  D) 31N
  Show Answer
  The correct answer is D .
• Question 823: If in a simple pendulum experiment the length of the inextensible string is increased by a factor of four, its period is increased by a factor of Options:
  A) 4
  B) $\frac{\pi }{2}$
  C) $\frac{1}{4}$
  D) 2$\pi$
  E) 2
  Show Answer
  The correct answer is E .
• Question 824:

  An air bubble of radius 4.5 cm initially at a depth of 12 m below the water surface rises to the surface. If the atmospheric pressure is equal to 10.34 m of water, the radius of the bubble just before it reaches the water surface is

  Options:
  A) 6.43 cm
  B) 8.24 cm
  C) 4.26 cm
  D) 5.82 cm
  Show Answer
  The correct answer is D .
• Question 825: A ray of light passing through the centre of curvature of a concave mirror is reflected by the mirror at Options:
  A) 0^o
  B) 45^o
  C) 90^o
  D) 180^o
  Show Answer
  The correct answer is A .
• Question 826: How many grams of water at 17^oC must be added to 42g of ice at 0^oC to melt the ice completely? [specific latent heat of fusion of ice = 3.4 x 10⁵Jkg^-1, specific heat capacity of water = 4200Jkg^-1k^-1] Options:
  A) 200g
  B) 300g
  C) 320g
  D) 400g
  Show Answer
  The correct answer is A .
• Question 827:

  A certain radioactive source emits radiation that was found to be deflected by both magneticand electric fields. The radiation is?

  Options:
  A) beta rays
  B) gamma rays
  C) x-rays
  D) ultra-violet rays
  Show Answer
  The correct answer is A .
• Question 828:

  A device that converts sound energy into electrical energy is

  Options:
  A) the horn of a motor car
  B) an A.C. generator
  C) a microphone
  D) the telephone
  E) radio waves
  Show Answer
  The correct answer is C .
• Question 829:



  From the diagram above, determine the value of the resistance X

  Options:
  A) 6Ω
  B) 9Ω
  C) 12Ω
  D) 15Ω
  Show Answer
  The correct answer is D .
• Question 830:


  The diagram above illustrates the penetrating power of some types of radiation. X, Y and Z are likely

  Options:
  A) X = α-particle; Y = γ-ray; Z = β-particle
  B) X = α-particle; Y = β-particle; Z = γ-ray
  C) X = γ-ray; Y = α-particle; Z = β-particle
  D) X = β-particle; Y = γ-ray; Z = α-particle
  Show Answer
  The correct answer is C .
