Physics is the science that studies the nature and properties of matter and energy. It covers topics like motion, heat, light, sound, electricity, magnetism, and the structure of atoms.

• Question 41:


  The diagram above illustrates the penetrating power of some types of radiation. X, Y and Z are likely

  Options:
  A) X = α-particle; Y = γ-ray; Z = β-particle
  B) X = α-particle; Y = β-particle; Z = γ-ray
  C) X = γ-ray; Y = α-particle; Z = β-particle
  D) X = β-particle; Y = γ-ray; Z = α-particle
  Show Answer
  The correct answer is C .
• Question 42: Calculate the heat energy lost when 10g of boiling water changes to ice at 0°C. [Specific latent heat of ice 336Jg^-1 . Specific heat capacity of water 4.2Jg^-1 K^-1] Options:
  A) 840J
  B) 3360J
  C) 3420J
  D) 4200J
  E) 7560J
  Show Answer
  The correct answer is E .
• Question 43: If the angle of declination in a place is 10^oE, calculate the true geographic bearing if the compass reads N40^oE Options:
  A) N50^oE
  B) N40^oE
  C) N30^oE
  D) N25^oE
  Show Answer
  The correct answer is C .
• Question 44: Which of the following is TRUE of light and sound waves? Options:
  A) they both transmit energy
  B) they both need a mediumfor propagation
  C) they are both transverse waves
  D) their velocities in air are equal
  Show Answer
  The correct answer is A .
• Question 45:



  A beam of radiation is passed between a pair of charged plates as indicated in the fig above. Beam P is undetected While Q is deflected to the left. P and Q respectively should be

  I.γ-rays β-rays
  II. x-rays β-rays
  III. γ-rays x-rays
  IV. x-rays x-rays

  Options:
  A) I only
  B) III only
  C) I and II
  D) III and IV
  Show Answer
  The correct answer is A .
• Question 46:

  A reservoir is filled with liquid of density 2000 kgm${}^{-1}$. Calculate the depth at which the pressure in the liquid will be equal to 9100 Nm${}^{-2}$ (g = 10 ms${}^{-2}$)

  Options:
  A) 0.262 m
  B) 0.664 m
  C) 0.819 m
  D) 0.455 m
  Show Answer
  The correct answer is D .
• Question 47: In an operating X-ray tube, a high p.d is applied between the cathode and the anode for the purpose of Options:
  A) accelerating the electrons to a very high energy
  B) concentrating electrons on the target
  C) heating the anode
  D) heating the cathode
  E) producing a stream of electrons
  Show Answer
  The correct answer is A .
• Question 48:

  Calculate the temperature of 6 moles of an ideal gas at a pressure of 7.6 x 10⁶Nm^-2 with a volume of 10^-3m³.

  [R = 8.3jmol^-1K^-1]

  Options:
  A) 201^oC
  B) 126^oC
  C) 153^oC
  D) 185^oC
  Show Answer
  The correct answer is C .
• Question 49:

  A man will exert the greatest pressurewhen he?

  Options:
  A) lies flat on his back
  B) lies on his belly
  C) stands on both feet
  D) stands on the toes of one foot
  Show Answer
  The correct answer is D .
• Question 50: A series RLC circuit is said to resonate, when Options:
  A) capacitive reactance is zero
  B) conductance is maximum
  C) current is minimum
  D) impedance is minimum
  E) inductive reactance is zero
  Show Answer
  The correct answer is D .
