Physics is the science that studies the nature and properties of matter and energy. It covers topics like motion, heat, light, sound, electricity, magnetism, and the structure of atoms.

• Question 371:

  A 40KW electric cable was uses to transmit electricity through a resistor of resistance 2.00Ω at 800V. The power loss as internal energy is

  Options:
  A) 4.0 x 10²W
  B) 5.0 x 10²W
  C) 4.0 x 10³W
  D) 5.0 x 10³W
  Show Answer
  The correct answer is D .
• Question 372: When a transformer has more secondary windings than primary windings, it Options:
  A) has a smaller secondary current
  B) has a greater power output
  C) is a step-down transformer
  D) increases the total energy output
  Show Answer
  The correct answer is C .
• Question 373:



  In the diagram above, if the internal resistance of the cell is zero, the ration of the powers P₁ and P₂ dissipated by R₁ and R₂

  Options:
  A) ^R₂/_R1
  B) ^R₁/_R2
  C) ^R₁+R₂/_R1
  D) ^R₁+R₂/_R2
  Show Answer
  The correct answer is A .
• Question 374: If a metal wire 4m long and cross-sectional area 0.8 mm² has a resistance of 60, find the resistivity of the wire Options:
  A) 5.3x10^-7
  B) 3.0x10^-5
  C) 1.2x10^-6
  D) 3.2x10^-6
  Show Answer
  The correct answer is C .
• Question 375: A wire of length 100cm and cross-sectional area 2.0 × 10^-3cm² has a resistance of 0.10 ω. Calculate its electrical conductively. Options:
  A) 2.0 × 10-6 ω^-1cm^-1
  B) 5.0 × 10-5 ω^-1cm^-1
  C) 2.0 × 106 ω^-1cm^-1
  D) 5.0 × 106 ω^-1cm^-1
  E) 5.0 × 107 ω^-1cm^-1
  Show Answer
  The correct answer is B .
• Question 376:

  In an AC circuit, resonance occurs when the impedance of the circuit is:

  Options:
  A) Zero
  B) Maximum
  C) Equal to the capacitive reactance of the circuit
  D) Minimum
  Show Answer
  The correct answer is D .
• Question 377:



  The figure above shows a uniform wood of weight 200N and length 50m. It is pivoted at one end and suspended by a cord at the other end at an angle of 30 degrees to the wood. Calculate the tension in the cord if the wood is horizontal.

  Options:
  A) 10N
  B) 20N
  C) 100N
  D) 200N
  Show Answer
  The correct answer is D .
• Question 378: Calculate the work done in charging a capacitor of capacitance 20µF through a potential difference of 1000V. Options:
  A) 0.02 J
  B) 0.10 J
  C) 0.20 J
  D) 1.00 J
  E) 10.00 J
  Show Answer
  The correct answer is E .
• Question 379: A converging lens of focal length 5cm forms a virtual image which is 10cm from the lens. How far from the lens is the object? Options:
  A) 2.0cm
  B) 3.3cm
  C) 5.0cm
  D) 10.0cm
  E) 15.0cm
  Show Answer
  The correct answer is E .
• Question 380:

  Arrange the following in the order of their increasing frequency.I. Visible light

  II. Gamma rays

  III. Radio waves

  IV. Infra-red radiation

  V. Ultra-violet radiation

  Options:
  A) I, II, III, IV, V
  B) II, III, IV, V, I
  C) III, IV, V, I, II
  D) IV, III, I. V, II
  E) III, IV, I,V, II
  Show Answer
  The correct answer is E .
