Physics is the science that studies the nature and properties of matter and energy. It covers topics like motion, heat, light, sound, electricity, magnetism, and the structure of atoms.

• Question 1: The current in a reverse-biased junction is due to? Options:
  A) minority carriers
  B) electrons
  C) majority carriers
  D) holes
  Show Answer
  The correct answer is A .
• Question 2:



  The diagram above shows two capacitors P and Q of capacitance 5μF and 10μF. Find the charges stored in P and Q respectively

  Options:
  A) 2μC and 4μC
  B) 4μC and 2μC
  C) 100μC and 200μC
  D) 200μC and 100μC
  Show Answer
  The correct answer is C .
• Question 3:



  In the above fig, PQ and R are vectors, which of the following options, gives a correct relationship between the vectors

  Options:
  A) P = Q + R
  B) P = Q - R
  C) P = R - Q
  D) P + Q + R = O
  Show Answer
  The correct answer is A .
• Question 4:



  The diagram above represents a transverse electromagnetic wave travelling with speed 3.0 x 10⁸ms^-1. What is the frequency of the wave.

  Options:
  A) 3.0 x 10⁷Hz
  B) 9.0 x 10⁷Hz
  C) 1.0 x 10⁹Hz
  D) 3.0 x 10⁹Hz
  Show Answer
  The correct answer is D .
• Question 5: A galvanometer of resistance 20$\mathrm{\Omega }$ is to be provided with a shunt that $\frac{1}{10}$ of the whole current in a circuit passes through the galvanometer. The resistance of the shunt is Options:
  A) 2.00$\mathrm{\Omega }$
  B) 2.22$\mathrm{\Omega }$
  C) 18.00$\mathrm{\Omega }$
  D) 18.22$\mathrm{\Omega }$
  Show Answer
  The correct answer is B .
• Question 6: Which of the following is a derived unit? Options:
  A) Kilogramme
  B) Meter
  C) Kelvin
  D) Newton
  Show Answer
  The correct answer is D .
• Question 7: A mirror of weight 75N is hung by a cord from a hook on the wall. If the cord makes an angle of 30^o with horizontal, the tension in the cord is Options:
  A) 100N
  B) 1500N
  C) 250N
  D) 150N
  Show Answer
  The correct answer is D .
• Question 8:



  In the figure above if the atmospheric pressure is 760mm, the pressure of the chamber G is

  Options:
  A) 660mm
  B) 690mm
  C) 830mm
  D) 860mm
  Show Answer
  The correct answer is C .
• Question 9: A cell of internal resistance 0.01Ω can be measured accurately using the Options:
  A) Ohm meter
  B) metre bridge
  C) potentiometer
  D) electroscope
  Show Answer
  The correct answer is C .
• Question 10: Which type of radiation does not NOT originate within the nucleus? Options:
  A) alpha
  B) beta
  C) gamma
  D) neutron
  E) x-rays
  Show Answer
  The correct answer is E .
